● Programmable Z axis, automatically control depth and generator settings from roughing to finishing cycles
●1 micron resolution linear scales, provide closed loop and position feedback for precise part positioning accuracy.
● High Quality cast iron for increase rigidity and work piece capacity with heat treated work table.
● Special circuit for tungsten steel machining (Optional).
● Compact design saving up to 30% space by oil tank design in the based and generator attached with machine.
●1 micron resolution linear scales, provide closed loop and position feedback for precise part positioning accuracy.
● High Quality cast iron for increase rigidity and work piece capacity with heat treated work table.
● Special circuit for tungsten steel machining (Optional).
● Compact design saving up to 30% space by oil tank design in the based and generator attached with machine.
| Item | Unit | C26 | |
| X/Y/Z Travel | mm | 300 × 250 × 150 | |
| U Travel | mm | 150 | |
| Work Table Size(L×W) | mm | 600 × 300 | |
|
Max.
Work Piece Dimension(L×W×H)-Flush |
mm | 750 × 500 × 240 | |
|
Max.
Work Piece Dimension(L×W×H)-Submerge |
mm | 750 × 500 × 180 | |
| Max. Work Piece Weight | kg | 800 | |
| Max. Electrode Weight | kg | 100 | |
|
Distance
From Work Table To Electrode Plate |
mm | 190-490 | |
| Max. Machining Current | Amp | 30 | |
| Power Input | KVA | 3 | |
| Max. Dielectric Level | mm | 190 | |
| Dielectric Unit Capacity | Liter | 250 | |
| Fliter | pcs | 2 | |
| Machine Net Weight | kg | 1700 | |
|
Machine Dimension |
mm |
1750 × 1875 × 2450 |
|
|
Standard Accessories |
|
Filter x 2 pcs |
|
Tool Box 1 set |
|
1/2" chuck x 1 pc |
|
Nozzle x 2 pcs |
|
Extinguisher x 1 pc |
|
Operation Manual x 1 pc |
|
Working lamp x 1 pc |
|
Manual Lubricator x 1 set |
Optional Accessories
Magnet 6"x14" or 8"x16"
Tungsten Carbide Circuit
Dielectric Cooler
Pendant Style Control Panel
